Used AIDA Mechanical Presses are available for PDA-30H, PMX-300, NC2-250, TMX-300, PMX-L2-6000, NS-800, HMX-125, CFT-1000, and S1-500

AIDA	AIDA	AIDA	AIDA	AIDA
CFT-1000 with Trasnfer Unit	NC2-250	NC2-250 + feeding	TMX-S2-300	TMX-S2-300 + Mech Transfer
Mfg Year : 1983	Mfg Year : 1994	Mfg Year : 2015	Mfg Year : 2008	Mfg Year : 1998
Model : CFT-1000	Model : NC2-250	Model : NC2-250	Model : TMX-S2-300	Model : TMX-S2-300
Capacity : 1000 ton	Capacity : 250 ton	Capacity : 250 ton	Capacity : 300 ton	Capacity : 300 ton
Stroke : 250 mm	Stroke : 280 mm	Stroke : 280 mm	Stroke : 300 mm	Stroke : 350 mm
SPM : 20-35	SPM : 20-35	SPM : 20-35	SPM : 20-40	SPM : 20-30
Die Height : 600 mm	Die Height : 550 mm	Die Height : 550 mm	Die Height : 700 mm	Die Height : 700 mm
Slide Adj : 30 mm	Slide Adj : 120 mm	Slide Adj : 120 mm	Slide Adj : 100 mm	Slide Adj : 50 mm
Slide area : 1500 x 1100 mm	Slide area : 2100 x 700 mm	Slide area : 2100 x 700 mm	Slide area : 3000 x 1200 mm	Slide area : 2500 x 1000 mm
Bolster area : 1500 x 1200 mm	Bolster area : 2700 x 820 mm	Bolster area : 2100 x 820 mm	Bolster area : 3000 x 1200 mm	Bolster area : 2500 x 1000 mm
Main Motor : 130 kw	Main Motor : 30 kw	Main Motor : 30 kw	Main Motor : 55 kw	Main Motor : 55 kw
Bed Kockout : 5 satges	Max. Upper die Wt : 1.65 ton			Max. Upper die Wt : 2.0 ton
Bed Kockout capacity : 50 ton		3-in-1 Orii :	Transfer Unit
		Model : LCC04K-J3	Feed Stroke : 500 mm	Mech Trasnfer Unit :
Trasnfer Unit (Model : FTO-20)		Width : 50-400 mm	Clamp Stroke : 100 mm	Feed : 300 mm, Clamp : 120 mm
Feed Pitch : 200 mm		Thcikness : 0.3-3.2 mm	Lifting Stroke : 60 mm	Lift : 60 mm
Clamping Stroke : 70 mm		Coil Weight : 2.0 ton
Lift stroke : 30 mm		Coil ID : 508 mm
		Coil ID : 1200 mm
		Feedd length : 10- 400 mm
Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set
M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand	M/C Location : China	M/C Location : Thailand

Used Komatsu Mechanical Presses are available for E2W-200, L2M-600, E2G-600, H2F-600

KOMATSU	KOMATSU	KOMATSU	KOMATSU	KOMATSU
E2W-200 + Leveler Feed	L2M-600 + Leveler Feed	L2M-600	E2G-600	H2F-600B Servo Press
Mfg Year : 2003 and 2001	Mfg Year : 2014	Mfg Year : 2007	Mfg Year : 2007	Mfg Year : 2007
Model : E2W-200	Model : L2M-600	Model : L2M-600	Model : E2G-600	Model : H2F-600B Servo Press
Capacity : 200 ton	Capacity : 600 ton	Capacity : 600 ton	Capacity : 600 ton	Capacity : 600 ton
Stroke : 150 mm	Stroke : 250 mm	Stroke : 300 mm	Stroke : 300 mm	Stroke : 500 mm
SPM : 30-70	SPM : 30-70	SPM : 20-50	SPM : 12-25	SPM : 20-50
Die Height : 500 mm	Die Height : 650 mm	Die Height : 700 mm	Die Height : 750 mm	Die Height : 750 mm
Slide Adj : 120 mm	Slide Adj : 200 mm	Slide Adj : 350 mm	Slide Adj : 200 mm	Slide Adj : 200 mm
Slide area : 1850 x 650 mm	Slide area : 2450 x 1200 mm	Slide area : 4600 x 1550 mm	Slide area : 2700 x 1750 mm	Slide area : 2700 x 1750 mm
Bolster area : 2150 x 850 mm	Bolster area : 2450 x 1300 mm	Bolster area : 4600 x 1550 mm	Bolster area : 2700 x 1900 mm	Bolster area : 2700 x 1900 mm
	Main Motor : 75 kw	Main Motor : 75 kw	Max. Upper die Wt : 6.0 ton	Max. Upper die Wt : 6.0 ton
	Max. Upper die Wt : 5.0 ton	Max. Upper die Wt : 10.0 ton
3-in-1 Leveler Feeder : Provided	Leveler Feeding : Orii
	: W=600, T=6.0 mm
Q'ty available : 2 set	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 5 set	Q'ty available : 1 set
M/C Location : Thailand	M/C Location : Thailand	M/C Location : China	M/C Location : Thailand	M/C Location : Thailand

Used HITACHI ZOSEN FUKUI Mechanical Presses are available for 170 ton Transfer Press

HITACHI ZOSEN	NAME PLATE	LINE VIEW	LINE VIEW	LINE VIEW
1700 ton Trasnfer Press	1700 ton Trasnfer Press	1700 ton Trasnfer Press	1700 ton Trasnfer Press	1700 ton Trasnfer Press
Mfg Year : 1977
Model : TR8-1700-1000x6-230
Capacity : 1700 ton
Stroke : 650 mm
SPM : 8-20
Die Height : 1350 mm
Slide Adj : 50 mm
Slide area : 3000 x 2300 mm x 2
Bolster area : 3000 x 2300 mm x 2
Main Motor : DC Motor
Max. Upper die Wt : 20 ton
Transfer Unit :
Feed Stroke : 1000 mm
Clamping Stroke : 250 mm
Lifting Stroke : 150 mm
No. of stages : 6
Q'ty available : 1 set
M/C Location : Thailand

Used SEYI Mechanical Presses are available for 400 ton model : SNS2-400, SAG-250, SAG-400, SN1-160, SN2-200, SN2-300,
SNS2-200, SEL4-1600, SE4-800, SE4-600 Tandem Press Line

SEYI	SEYI	SEYI	SEYI	SEYI
SNS2-300	SEL4-1600	SE4-800	SE4-600	SAG-600
Mfg Year : 2015	Mfg Year : 2018	Mfg Year : 2018	Mfg Year : 2018	Mfg Year : 2008
Model : SNS2-300	Model : SEL4-1600	Model : SE4-800	Model : SE4-600	Model : SAG-600
Capacity : 300 ton	Capacity : 1600 ton	Capacity : 800 ton	Capacity : 600 ton	Capacity : 600 ton
Stroke : 280 mm	Stroke : 1000 mm	Stroke : 900 mm	Stroke : 900 mm	Stroke : 450 mm
SPM : 20-35	SPM : 10-20	SPM : 10-20	SPM : 12-22	SPM : 12-22
Die Height : 550 mm	Die Height : 1500 mm	Die Height : 1500 mm	Die Height : 1500 mm	Die Height : 700 mm
Slide Adj : 120 mm	Slide Adj : 700 mm	Slide Adj : 700 mm	Slide Adj : 700 mm	Slide Adj : 250 mm
Slide area : 3100 x 900 mm	Slide area : 4000 x 2200 mm	Slide area : 4000 x 2200 mm	Slide area : 4000 x 2200 mm	Slide area : 3100 x 1550 mm
Bolster area : 3400 x 1000 mm	Bolster area : 4000 x 2200 mm	Bolster area : 4000 x 2200 mm	Bolster area : 4000 x 2200 mm	Bolster area : 3100 x 1550 mm
Main Motor : 40 HP x 4P	Main Motor : 250 HP x 4P	Main Motor : 100 HP x 4P	Main Motor : 75 HP x 4P	Main Motor : 100 HP
Braking time : 144 ms	Moving Bolster : 2 sets (L-R Exit)	Moving Bolster : 2 sets (L-R Exit)	Moving Bolster : 2 sets (L-R Exit)	Braking time : 234 ms
Die Cushion : 2-pad-2-cylinder	Die Cushion : 1-pad-2-cylinder	Die Cushion : N/A	Die Cushion : N/A
Cushion Force : 14 ton x 2	Cushion Force : 300 ton
Cushion pad : 700 x 450 mm x 2	Cushion pad : 3500 x 1700 mm
	Cushion Stroke : 25-350 mm
	Cushion Lock device : Provided
Power Supply : 3 Ph. 380VAC 50Hz	Power Supply : 3 Ph. 380VAC 50Hz	Power Supply : 3 Ph. 380VAC 50Hz	Power Supply : 3 Ph. 380VAC 50Hz	Power Supply : 3 Ph. 380VAC 50Hz
Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 2 sets	Q'ty available : 2 sets	Q'ty available : 1 set
M/C Location : China	M/C Location : China	M/C Location : China	M/C Location : China	M/C Location : Thailand
SEYI
SAG-600
Mfg Year : 2006
Model : SAG-600
Capacity : 600 ton
Stroke : 250 mm
SPM : 25-50
Die Height : 700 mm
Slide Adj : 250 mm
Slide area : 4600 x 1550 mm
Bolster area : 4600 x 1550 mm
Main Motor : 100 HP
Braking time : 265 ms
Power Supply :
3 Ph. 380VAC 50Hz
Q'ty available : 1 set
M/C Location : China

Used Fon Yu Mechanical Presses are available for 1500 ton, 1200 ton, 800 ton and 600 ton Tandem Press Line.
Used Fon Yu Mechanical Presses are available for 2-point 800 ton, 500 ton, 500 ton and 500 ton Tandem Press Line.

FON YU	FON YU	FON YU	FON YU	FON YU
LINE VIEW	1500 ton	1200 ton	800 ton	600 ton
	Mfg Year : 2008	Mfg Year : 2008	Mfg Year : 2007	Mfg Year : 2007
	Model : FLP-1500	Model : FLP-1200	Model : FLP-800	Model : FLP-600
	Capacity : 1500 ton	Capacity : 1200 ton	Capacity : 800 ton	Capacity : 600 ton
	Stroke : 900 mm	Stroke : 850 mm	Stroke : 850 mm	Stroke : 850 mm
	SPM : 8-18	SPM : 8-18	SPM : 8-18	SPM : 8-18
	Die Height : 1500 mm	Die Height : 1500 mm	Die Height : 1500 mm	Die Height : 1500 mm
	Slide Adj : 600 mm	Slide Adj : 400 mm	Slide Adj : 400 mm	Slide Adj : 400 mm
	Slide area : 4600 x 2200 mm	Slide area : 4600 x 2200 mm	Slide area : 4600 x 2200 mm	Slide area : 4600 x 2200 mm
	Bolster area : 4600 x 2200 mm	Bolster area : 4600 x 2200 mm	Bolster area : 4600 x 2200 mm	Bolster area : 4600 x 2200 mm
	Main Motor : 350 HP	Main Motor : 200 HP	Main Motor : 150 HP	Main Motor : 125 HP
	Die Cushion : 300 ton	Die Cushion : N/A	Die Cushion : N/A	Die Cushion : N/A
	Moving Bolster : Front Exit x 1	Moving Bolster : Front Exit x 1	Moving Bolster : Front Exit x 1	Moving Bolster : Front Exit x 1
	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set
	M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand
FON YU	FON YU	FON YU	FON YU	FON YU
LINE VIEW-800/500/500/500	2-point_800 ton	2-point_500 ton	2-point_500 ton	2-point_500 ton
	Mfg Year : 2012	Mfg Year : 2012	Mfg Year : 2012	Mfg Year : 2012
	Model : FLP-800	Model : FLP-500	Model : FLP-500	Model : FLP-500
	Capacity : 800 ton	Capacity : 500 ton	Capacity : 500 ton	Capacity : 500 ton
	Stroke : 650 mm	Stroke : 650 mm	Stroke : 650 mm	Stroke : 650 mm
	SPM : 16-20	SPM : 16-20	SPM : 16-20	SPM : 16-20
	Die Height : 1000 mm	Die Height : 1000 mm	Die Height : 1000 mm	Die Height : 1000 mm
	Slide Adj : 400 mm	Slide Adj : 400 mm	Slide Adj : 400 mm	Slide Adj : 400 mm
	Slide area : 3600 x 1800 mm	Slide area : 3600 x 1800 mm	Slide area : 3600 x 1800 mm	Slide area : 3600 x 1800 mm
	Bolster area : 3600 x 1800 mm	Bolster area : 3600 x 1800 mm	Bolster area : 3600 x 1800 mm	Bolster area : 3600 x 1800 mm
	Main Motor : 250 HP	Main Motor : 150 HP	Main Motor : 150 HP	Main Motor : 150 HP
	Die Cushion : 160 ton	Die Cushion : 100 ton	Die Cushion : N/A	Die Cushion : N/A
	Cushion Pad : 3210 x 1410 mm	Cushion Pad : 3210 x 1410 mm
	Cushion Stroke : 250 mm	Cushion Stroke : 250 mm
	Moving Bolster : L-R Exit x 2 sets	Moving Bolster : L-R Exit x 2 sets	Moving Bolster : L-R Exit x 2 sets	Moving Bolster : L-R Exit x 2 sets
	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set
	M/C Location : China	M/C Location : China	M/C Location : China	M/C Location : China

Used Lien Chien Hydraulic Presses are available for 2400 ton, 1200 ton, 1200 ton, 800 ton and 800 ton Tandem Press Line.

LIEN CHIEN HYDRAULIC
2400, 1200, 800 TON

Used Brother Tapping Center are available : TC-S2A, TC-R2A, TC-S2B, TC-20A, TC-31B

BROTHER	BROTHER	BROTHER	BROTHER	BROTHER
TC-S2A	TC-R2A	TC-S2B	TC-20A	TC-31B
Mfg Year : 2004-2010	Mfg Year : 2004-2010	Mfg Year : 2004	Mfg Year : 2006-2010	Mfg Year : 2006
Q'ty available : 5 set	Q'ty available : 5 sets	Q'ty available : 4 sets	Q'ty available : 20 sets	Q'ty available : 1 sets
M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand

Used Amada Press is available for 110 ton Model : TP-110

AMADA
TP-110
Mfg Year : 1993
Model : TP-110
Capacity : 110 ton
SPM : 60-120
Stroke : 110 mm
Die Height : 320 mm
Slide Adj : 100 mm
Slide area : 600 x 500 mm
Bolster area : 1100 x 540 mm
Main motor : 11 kw x 4 P
3-in-1 leveller Feeder :
Brand : Aida
Q'ty available : 1 set
M/C Location : Thailand

Used PATEC Mechanical Presses are available : FGL-600, FGL-200S, E4H-250

PATEC	PATEC	PATEC
FGL-600	FGL-200S	E4H-250
Mfg Year : 2005	Mfg Year : 2007	Mfg Year : 2005
Model : FGL-600	Model : FGL-200S	Model : E4H-250
Capacity : 600 ton	Capacity : 200 ton	Capacity : 250 ton
Stroke : 150 mm	Stroke : 100 mm	Stroke : 150 mm
SPM : 35-70	SPM : 50-100	SPM : 40-80
Die Height : 550 mm	Die Height : 400 mm	Die Height : 450 mm
Slide Adj : 50 mm	Slide Adj : 50 mm	Slide Adj : 50 mm
Slide area : 2100 x 800 mm	Slide area : 1100 x 600 mm	Slide area : 2200 x 700 mm
Bolster area : 2100 x 1000 mm	Bolster area : 1100 x 600 mm	Bolster area : 2200 x 800 mm
Main Motor : 75 kw x 4P	Main Motor : 22 kw x 4P	Main motor : 30 kw x 4P
Accessories	Accessories	Accessories
Orii 3-in-1 Leveller Feeder	Orii 3-in-1 Leveller Feeder	DATEC NC Feeder +
Max Width : 600 mm	Max Width : 400 mm	2-in-1 Leveller
Max Thickness : 9.0 mm	Max Thickness : 3.2 mm	Max Width : 400 mm
Coil Weight : 5.0 ton	Coil Weight : 2.0 ton	Max Thickness : 3.2 mm
		Coil Weight : 1.5 ton
Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set
M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand

Used HITACHI ZOSEN FUKUI Mechanical Presses are available for 170 ton Transfer Press

HITACHI ZOSEN	NAME PLATE	LINE VIEW	LINE VIEW	LINE VIEW
1700 ton Trasnfer Press	1700 ton Trasnfer Press	1700 ton Trasnfer Press	1700 ton Trasnfer Press	1700 ton Trasnfer Press
Mfg Year : 1977
Model : TR8-1700-1000x6-230
Capacity : 1700 ton
Stroke : 650 mm
SPM : 8-20
Die Height : 1350 mm
Slide Adj : 50 mm
Slide area : 3000 x 2300 mm x 2
Bolster area : 3000 x 2300 mm x 2
Main Motor : DC Motor
Max. Upper die Wt : 20 ton
Transfer Unit :
Feed Stroke : 1000 mm
Clamping Stroke : 250 mm
Lifting Stroke : 150 mm
No. of stages : 6
Q'ty available : 1 set
M/C Location : Thailand

Used AIDA Mechanical Presses are available for PDA-30H, PMX-300, NC2-250, TMX-300, PMX-L2-6000, NS-800, HMX-125, CFT-1000, and S1-500

AIDA	AIDA	AIDA	AIDA	AIDA
CFT-1000 with Trasnfer Unit	NC2-250	NC2-250 + feeding	TMX-S2-300	TMX-S2-300 + Mech Transfer
Mfg Year : 1983	Mfg Year : 1994	Mfg Year : 2015	Mfg Year : 2008	Mfg Year : 1998
Model : CFT-1000	Model : NC2-250	Model : NC2-250	Model : TMX-S2-300	Model : TMX-S2-300
Capacity : 1000 ton	Capacity : 250 ton	Capacity : 250 ton	Capacity : 300 ton	Capacity : 300 ton
Stroke : 250 mm	Stroke : 280 mm	Stroke : 280 mm	Stroke : 300 mm	Stroke : 350 mm
SPM : 20-35	SPM : 20-35	SPM : 20-35	SPM : 20-40	SPM : 20-30
Die Height : 600 mm	Die Height : 550 mm	Die Height : 550 mm	Die Height : 700 mm	Die Height : 700 mm
Slide Adj : 30 mm	Slide Adj : 120 mm	Slide Adj : 120 mm	Slide Adj : 100 mm	Slide Adj : 50 mm
Slide area : 1500 x 1100 mm	Slide area : 2100 x 700 mm	Slide area : 2100 x 700 mm	Slide area : 3000 x 1200 mm	Slide area : 2500 x 1000 mm
Bolster area : 1500 x 1200 mm	Bolster area : 2700 x 820 mm	Bolster area : 2100 x 820 mm	Bolster area : 3000 x 1200 mm	Bolster area : 2500 x 1000 mm
Main Motor : 130 kw	Main Motor : 30 kw	Main Motor : 30 kw	Main Motor : 55 kw	Main Motor : 55 kw
Bed Kockout : 5 satges	Max. Upper die Wt : 1.65 ton			Max. Upper die Wt : 2.0 ton
Bed Kockout capacity : 50 ton		3-in-1 Orii :	Transfer Unit
		Model : LCC04K-J3	Feed Stroke : 500 mm	Mech Trasnfer Unit :
Trasnfer Unit (Model : FTO-20)		Width : 50-400 mm	Clamp Stroke : 100 mm	Feed : 300 mm, Clamp : 120 mm
Feed Pitch : 200 mm		Thcikness : 0.3-3.2 mm	Lifting Stroke : 60 mm	Lift : 60 mm
Clamping Stroke : 70 mm		Coil Weight : 2.0 ton
Lift stroke : 30 mm		Coil ID : 508 mm
		Coil ID : 1200 mm
		Feedd length : 10- 400 mm
Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set	Q'ty available : 1 set
M/C Location : Thailand	M/C Location : Thailand	M/C Location : Thailand	M/C Location : China	M/C Location : Thailand

Download Catalog

Download Catalog

Download Catalog

Download Catalog

Download Catalog

Download Catalog

Download Catalog

Download Catalog

Download Catalog

Download Catalog
